Incazelo Yemikhiqizo
Iphaneli ye-Grahowlet engu-5-Intshi ye-Capacitive Touch
ukuqhathaniswa kwemingcele yomkhiqizo
| Igama lemikhiqizo |
Iphaneli ye-Grahowlet engu-5-Intshi ye-Capacitive Touch |
Ibhrendi |
I-Grahowlet |
| Imodeli yemikhiqizo | I-HX0501601 | Usayizi | 5intshi |
| Izinga Lokushisa Lokusebenza | -20degree ~ 70degree , Ngaphansi noma kulingana no-85%RH | Isilawuli IC | I-Cypress |
| Izinga Lokushisa Lesitoreji | -30degree ~80degree , Ngaphansi noma kulingana no-85%RH | Amaphuzu Wokuthinta | 10 amaphuzu |
| I-Outline Dimension | 120.7(W)×76.3(H)×1.45(D)mm | Isixazululo | 800×480 |
| Indawo yokubuka | 108.8(W)×65.5(H)mm | Ukusebenza kwe-Bonding | I-Air/Optical Bonding |
| Indawo Esebenzayo | 108(W)×64.8(H)mm | Isicelo | Isicelo sezimboni |
| Uhlelo Lokusekela | IWindows/Android/Linux Etc. | Uhlobo lwesixhumi esibonakalayo | I-IIC/USB |
| Iwaranti | 1 unyaka | Isakhiwo | G+G |
| I-Voltage Yokuhlinzeka Amandla | 5V | Ukukhanya | 600cd/m2 |
| Ukungafihli | Kukhulu noma kulingana no-85% | Ukuqina Kobuso |
Kukhulu noma kulingana no-6H |
10-I-POINT MULTI-TOUCH USEKELO
Izwa ukubonakala kokuthinta kweminwe okungenazihibe, okusabela kakhulu{0}}okuningi ngobuchwepheshe bokuthinta obunemba okuyi-10{3}}bephoyinti elingu-10 le-capacitive. Ukuthi ucindezela ukuze usondeze, izithombe ezizungezisayo, noma ukwenza{4}}imiyalo yezandla eminingi eyinkimbinkimbi, le mojula yesibonisi iletha ukusebenzisana okushelelayo, okungenasici okuthuthukisa ukukhiqiza nokusebenzelana komsebenzisi kuzo zonke izinhlelo zokusebenza.
UKUSEBENZA UKUTHIntwa KWAMANZI NAMANZI KASAWATI
Iklanyelwe ukusebenza kahle ezimeni ezimanzi nezinomswakama, le mojula yokuthinta i-capacitive igcina ukutholwa kokuthinta okunembile nanoma indawo yesikrini imbozwe ngamanzi, imvula, noma isifutho samanzi anosawoti. Ilungele amasistimu wokuzulazula olwandle, ama-kiosks angaphandle, izindawo zokucubungula ukudla, nanoma iyiphi indawo lapho ukuchayeka komswakama kungenakugwenywa.
I-UNIVERSAL GLOVE-UBUCHWEPHESHE BOKUTHINTA ABANGANE
I-Breakthrough touch{0}}ngokusebenzisa{1}}ikhono lamagilavu lisekela amagilavu azo zonke izinto zokwakha. Lesi sici siqeda isidingo sabasebenzisi sokususa izinto zokuzivikela, siqinisekise ukuhamba komsebenzi okungaphazamiseki ezimbonini, ezindaweni zokucwaninga, ezindaweni ezibandayo, nasezindaweni zokusebenza zangaphandle.
OKUPHELELAYO OKUPHEZULU KOMBONISO (Kukhulu noma kulingana nama-85%)
Jabulela izinto ezibukwayo ezicwebezelayo-ezinezimboni{1}}ezibonisa ngale okuhamba phambili okungu-85% noma ngaphezulu. Lokhu kuqinisekisa ukuthi ukubonisa okuqukethwe{4}}ukuthi umbhalo, imidwebo, noma ividiyo{5}}ibonakala inempilo, futhi iyiqiniso{{7}kumbala, okuthuthukisa ukufundeka nokunciphisa ukukhanga kwamehlo ngesikhathi sokusetshenziswa okunwetshiwe.
I-Hangzhou Hongxiao Technology Co., Ltd. iyibhizinisi likazwelonke-eliphezulu{3}}lobuchwepheshe elinekomkhulu e-Hangzhou, liphethe izitifiketi ezingaphezu kuka-30 ezihlanganisa amalungelo obunikazi bokusungula kanye namalungelo okushicilela esofthiwe. Inkampani igxile kakhulu ocwaningweni, ekuthuthukisweni, ekukhiqizweni nasekuthengisweni kwezikrini zokuthinta ezine-capacitive, izibonisi ze-LCD, amamojula wesikrini esithintwayo esine-capacitive, izikrini zokuthinta ze-industrial port, amamojula wokuthinta alaminated ngokugcwele, amabhodi omshayeli wesixhumi esibonakalayo, kanye nezingxenye zesakhiwo. Inkampani isebenzisa indawo yokukhiqiza ehlakaniphile yesimanje{7}}yemikhiqizo yetheminali yokusebenzisana yabantu. Amamojula ayo esikrini esithintwayo esinamandla athunyelwa ezinkulungwaneni zamakhasimende emhlabeni wonke futhi asetshenziswa kabanzi emikhakheni efana nemishini yezokwelapha, izinhlelo zokusebenza zezimoto, ulawulo lwezimboni, iziteshi zokushaja, izinhlelo zasekhaya ezihlakaniphile, izinto zikagesi ezihlakaniphile, ukuvikeleka okuhlakaniphile, imfundo ehlakaniphile, namarobhothi ahlakaniphile. Ngolwazi olubanzi kumboni{10}}izixazululo zephrojekthi ethile, inkampani iyakwazi ukuhlinzeka ngezixazululo zochwepheshe, ezenziwe ngokwezifiso kanye nezinsizakalo zobuchwepheshe kumakhasimende kuyo yonke imikhakha eyahlukene.
01
RICH Experience
Ngeminyaka engaphezu kwe-10 yobungcweti bemboni, inkampani yethu izitholele ukuthi ingumholi othembekile ekwakhiweni, ekuthuthukisweni, nasekukhiqizeni{1}}izikrini zokuthinta ezinamandla ezisebenza kahle.
02
Imishini Ethuthukisiwe
Amandla efekthri ahlanganisiwe ukusekela zonke izinhlobo zokwenza ngokwezifiso isikrini esithintwayo esinamandla, nge-glass substrate, isisekelo se-flim, i-optical adhesive(OCA), i-ITO ehlanganisa wonke amandla okukhiqiza impahla eluhlaza.
03
Ubuchwepheshe obuhle kakhulu
Siletha-izixazululo ze-capacitive ezibonisa ukuzwela okukhulu ezisekela{1}}ukuthinta okuningi, ukusebenza kwamagilavu, kanye{2}}nokusetshenziswa kwemvelo okunokhahlo. Ngokwenza ngokwezifiso okugcwele kwe-OEM/ODM ubuchwepheshe bethu buqinisekisa ukunemba, ukuqina, nolwazi oluhle kakhulu lomsebenzisi kuyo yonke imboni, yezokwelapha njll.
04
Isevisi yangokwezifiso
Sinikeza isevisi ephelele yangokwezifiso ye-OEM/ODM yezikrini zokuthinta ezine-capacitive - kusukela ekukhethweni kwezinto ezingavuthiwe (ingilazi engaphansi, i-ITO coating, i-OCA bonding) kuya ekwakhiweni kwesakhiwo, ukulungisa i-firmware, kanye nokuzivumelanisa nemvelo.
| Ukuhlolwa kwephrojekthi | 1 ~ 2 izinsuku zokusebenza |
| Amapulani | 2 ~ 3 izinsuku zokusebenza |
| Umkhiqizo Wangokwezifiso | 3 ~ 4weeks(Ngemva kokuba imidwebo isigunyaziwe) |
| Ukulethwa Kwemikhiqizo Eminingi | 4.3 ~ 5 amasonto |
| Amandla | 100k ngenyanga (10.1inches ukuze uthole inkomba) |
| umthamo wezobuchwepheshe | I-G+G/G+F+F,inqubo yokuvikela i-Full Lamination(OCR/OCA),ikhava yengilazi yokwelapha efana ne-AR,AG,AP,njll. |
| Ukusekela kwezobuchwepheshe | Izinjini zihlinzeka ngomnyango-u{1}}ziya{1}}ngeminyango noma izinsiza zokufinyelela ezikude phakathi kwamahora angu-24 |
| Iketanga lokuhlinzeka elizinzile eliqinisekisiwe okungenani iminyaka emi-3 kuye kwemi-5 | |
| Iwaranti{0}yonyaka owodwa kuyo yonke imikhiqizo yethu | |
Inkampani yethu ihlinzeka ngolwazi ngesakhiwo kanye nemininingwane engenziwa ngendlela oyifisayo ye-capacitive touch display module, ungqimba oluhlukaniswe ungqimba:
1. Ukuhlukaniswa Kwesendlalelo (kusuka phezulu kuye phansi)
◦ Ingilazi Yekhava: Isendlalelo esingaphandle esivikelayo sesikrini esithintwayo.
◦ Inzwa: Isendlalelo-esizwelayo{0}} esithola okokufaka komsebenzisi.
◦ Isikrini se-TFT: Iphaneli yokubonisa i-liquid crystal ekhiqiza okukhiphayo okubonakalayo.
◦ Ibhodi Le-Tcon (Ibhodi Lokulawula Isikhathi): Ibhodi labashayeli elicubungula amasignali futhi lishayela iphaneli yokubonisa.
2. Imininingwane eyenziwe ngokwezifiso
◦ PCAP (Cover Glass + Touch Sensor):
◦ Usayizi, Thinta IC, Umumo, Umbala, Ilogo, Ukuqina, Isixhumi esibonakalayo, Isakhiwo, i-FPC (Flexible Printed Circuit), Ukwelashwa kwendawo, izinga lokushisa elisebenzayo
◦ Iphaneli yokubonisa ye-TFT/OLED:
◦ Ukulungiswa, Ukukhanya, Isixhumi esibonakalayo, uphawu
◦ Ibhodi le-Tcon:
◦ Ibhodi lomshayeli we-HDMI/VGA, ibhodi lebhuloho elithi "IIC TO USB", Ibhodi Lokuguqulwa le-TFT, Isikrini Sembobo ye-Serial.
Inkampani yethu inikeze amakhasimende ethu ukubuka konke okuningiliziwe kwezingxenye, izici, kanye nezinsiza zemojuli yesikrini esithintwayo (i-TFT Bonded CTP):
1. Ukuhlukaniswa Kwengxenye
◦ I-Touch Screen Module (TFT Bonded CTP): Iyunithi yokubonisa yokuthinta ehlanganiswe ngokugcwele.
◦ Ilensi Yekhava (Ingilazi Yekhava):
◦ Izici: Amajamo angajwayelekile anama-cutouts atholakalayo; isekela ukuphrinta kukasilika namalogo ngokwezifiso; iyahambisana nemikhiqizo yengilazi efana ne-AGC, Corning, CG; ingelashwa nge-AG (I-Anti-Glare), i-AR (I-Anti-I-Reflective), i-AF (I-Anti-Izigxivizo zeminwe), noma ama-anti{3}}ama-explosion coatings; ongakhetha ukujiya kusukela 0.55mm ukuze 6.0mm.
◦ Inzwa yokuthinta:
◦ Izici: Izinto ezisetshenziswayo zifaka ingilazi, ifilimu, nefilimu-ku-ifilimu; ugqinsi kusuka ku-0.005mm kuya ku-1.1mm; izimo ze-FPC ezenziwe ngezifiso; isekela ama-touch IC brand afana ne-Cypress, i-Atmel Focaltech, i-Goodix, ne-EETI; izixhumanisi zifaka i-IIC, i-USB, i-SPI, ne-RS232.
◦ I-TFT LCD Display: Iphaneli yesibonisi engaphansi.
◦ Ukuhlanganisa: Kutholakala nge-Optical Bonding (OCA/OCR) noma ngezinqubo zokunamathela kohlaka.
2. Ulwazi Olwengeziwe
◦ Uma ufuna isixhumi esibonakalayo se-USB, singanikezela nge-IIC ebhodini lebhuloho le-USB.
Incazelo Yemikhiqizo
Izici Zomkhiqizo Zokuboniswa Kwesikrini Sokuthinta
Lesi sithombe sibonisa ukusebenza okubalulekile nezici zokwenza ngendlela oyifisayo imojula yesibonisi sokuthinta, nezincazelo ezilandelayo:
1. Glove Touch Compatibility
Isikrini esithintwayo sisekela okokufaka kokuthinta okunembile ngamagilavu azo zonke izinto zokwakha, ngisho nogqinsi oluhlanganisiwe olungafika ku-6mm.
Izinhlobo zamagilavu asekelwe zihlanganisa:
• Amagilavu enayiloni/ amagilavu e-latex/amagilavu kakotini/amagilavu woboya/amagilavu eqhwa
2. Amanzi/Amanzi/Amafutha Okumelana Nokuthinta
Umsebenzi wokuthinta uhlala uthembekile uma isikrini siveziwe noma sisebenza nge:
• Amanzi ahlanzekile/Amafutha/ 5% amanzi anosawoti (usawoti)
3. 8mm Ukuqhuma Okuwugqinsi{1}}Ingilazi Yekhava Yobufakazi
Isibonisi singahlonyiswa ngengilazi yekhava eqinile engu-8mm, enikeza ukumelana nomthelela ophezulu kanye{1}}nokusebenza kobufakazi bokuqhuma, kuyilapho kugcinwa ukusebenza kokuthinta okuvamile.
4. Ukwelashwa Kwekhava Yengilazi Yokuzikhethela (AG, AR, AF)
Ingilazi yekhava isekela izinhlobo ezintathu zokumbozwa okusebenzayo ukuthuthukisa ulwazi lomsebenzisi nokuqina:
• I-Anti-Glare (AG) Treatment
Iguqula ukukhanya okuqondile kube ukukhanya okusabalalisiwe esikrinini esithintwayo, isuse isibuko-njengokukhanya kanye nokunciphisa ukuxhopha.
• Ukwelapha-I-Reflective (AR).
Yengeza i-coating ukuze kuncishiswe ukukhanya okukhanyayo engilazini yekhava, yehlise ngokuphawulekayo ukubonakala kwesikrini futhi ithuthukise ukubonakala ekukhanyeni kwelanga okukhanyayo.
• Ukwelapha-Izigxivizo Zeminwe (AF).
Ifaka i-coating ukukhulisa ukushelela kwendawo, ukunciphisa ukumelana nokuslayida, amamaki amanzi ayinsalela, nezigxivizo zeminwe. Lokhu kuthuthukisa kokubili umuzwa wokuthinta kanye nokucaca okubonakalayo.
Isitifiketi
Izikrini zethu ze-capacitive touch screen zithole ifomu lezibuyekezo eziluhlaza ze-coustomer emhlabeni wonke, nezilinganiso ezingaguquki zezinkanyezi ezi-5 ezigqamisa ukusebenza kwazo okuthembekile, ukusabela okunembayo kokuthinta, kanye nezikwali ezihlukile ze-bulid.
1. Uhlu Olubanzi Lwemikhiqizo Ejwayelekile (1.3" ukuya ku-65")
Sinikeza izixazululo eziguquguqukayo ze-touch IC ngokusekela okuqinile kwezinhlelo zokusebenza eziningi zemboni, ezihambisana nezinsizakalo ezikhethekile neziqondene nomuntu. Izixazululo zethu zokuthinta zisekela:
• Ukusebenza kokuthinta ngamanzi akhona
• Thinta ngamagilavu enziwe ngazo zonke izinhlobo zezinto
• Thinta ngengilazi yekhava enogqinsi olungafika ku-20mm
2. Ethembekile, -Imikhiqizo Esebenzayo Ephakeme:
Imikhiqizo yethu ifaka ikhwalithi ezinzile, impilo ende yesevisi, nokusebenza okuphezulu{0}}okungaphazanyiswa. Sisekelwa ithimba lezobuchwepheshe eliqinile, sinikeza izinketho zemikhiqizo ehlukahlukene, okuhlanganisa amabhodi esilawuli enziwe ngokwezifiso kanye nezingxenye zohlaka lwensimbi, ukuze kuhlangatshezwane nezidingo ezithile zephrojekthi yakho.
3. Isikrini esithintwayo & Amakhono Wokukhiqiza Wokuboniswa
Izinsiza Zokukhiqiza Ezithuthukile
Sinezindlu zokuhlanza zeClass 1000 & Class 100, kanye nokukhipha okuzenzakalelayo kanye nemigqa yokukhiqiza{2}}ye-potting optical bonding ezenzakalelayo. Lezi zinsiza zisenza sikwazi ukunikeza uhla olugcwele lwezinqubo ezizenzakalelayo zezikrini zokuthinta kanye nezibonisi.
Ungathanda ukuthi ngihlanganise lezi zibe yinto eyodwa, ehlangene
imibuzo ejwayelekile ukubuzwa
Ungakwazi yini ukunikeza isevisi ye-OEM?
-
Yebo, sinikezela ngezinsizakalo ze-OEM ne-ODM futhi singenza ngokwezifiso imikhiqizo ngokusekelwe emidwebeni oyinikezayo.
Ngingayethemba kanjani ikhwalithi yomkhiqizo wakho?
+
-
Sinesipiliyoni seminyaka engaphezu kwe-10 embonini yesikrini esithintwayo. Kusukela ekuthengeni impahla kuya ekulethweni komkhiqizo, sinabasebenzi abangochwepheshe kanye nezinqubo zokuvimbela ubungozi bekhwalithi obungaba khona. Imikhiqizo yethu ivunyelwe yi-ROHS.
Ithini isevisi yakho-yangemuva kokuthengisa?
+
-
Uma kukhona izinkinga, uzothola impendulo yethu kungakapheli amahora angama-24. Isixazululo sizonikezwa ngaso leso sikhathi ithimba lethu lezobuchwepheshe neliqinile.
Ingakanani i-oda elincane?
+
-
:inkampani yethu isebenzelana kakhulu namadili amawholesale, kodwa uma ugcizelela ukuthi uthenge isethi eyodwa, wamukelekile ukuthi uthathe isampula ukuze uhlole ikhwalithi nomsebenzi. uma isampula seliqinisekisiwe, singavumela inani elincane lama-oda (akukho mkhawulo wenani) ukuthi lifakwe ekukhiqizeni futhi uma lokhu sekuqinisekisiwe, i-MOQ iyadingeka.
Singakanani isikhathi sewaranti semikhiqizo yakho?
+
-
Ngokuvamile iwaranti yonyaka ongu-1 ngaphandle kokulinyazwa izenzo zabantu ezinjengokusebenzisa kabi.Kuncike emikhiqizweni eyahlukene.
